SGM Single-Deck Service Refrigerated Gravity Coil Display Case

SGM

Resources

Sales Literature

Technical Reference Sheet

Drawings

Installation Manuals

Accessories

Service Single-Deck

Hillphoenix SGM Single-Deck, Service, Refrigerated, Gravity Coil Display. Designed for deli, meat and seafood applications. Fixed, vertical, thermopane, insulated glass. Available in several lengths and base heights. Lines up with the SSM and SGMO for a continuous department look.



Features and Benefits

  • C-frame with Bullet Leg Construction.
  • Standard 50”H with 10”H base frame height.
  • Exterior: Painted metal, including lower front panel above base.
  • Stainless steel base trim, front and sides.
  • Stainless steel exterior trim.
  • Painted metal outside back and rear base trim.
  • Stainless steel top sill.
  • Clear rear load doors with black frames.
  • 26”H – 7/8” thermopane, insulated regular-glare flat fixed front full length glass.
  • Stainless steel interior.
  • Interior trim to match interior.
  • Black plastic coil covers with fixed black wire rack.
  • LEDl canopy lighting.
  • Rear electrical box mounted behind the lower rear panel, customer left.
  • Oversized gravity coil meat model.
  • Solar digital thermometer.
  • Remote DX refrigeration package.



Available Options

  • Available lengths: 4’, 6’, 8’ and 12’.
  • Case heights available: 52” and 54”.
  • Alternate flexible base heights include: 8”, 10”, 12” and 14”H.
  • Extruded polymer base trim.
  • Painted metal base trim.
  • Master with nose bumper.
  • Cart bumper (for flat front profile).
  • Exterior stainless steel finish.
  • Solid surface or stone case top.
  • Integrated case top scale stand.
  • Adjustable scale stand.
  • White plastic coil covers.
  • Adjustable wire racks.
  • Heavy-duty stainless steel deck.
  • Reflective rear load doors.
  • 30”H – 7/8” thermopane, insulated regular-glare flat fixed front full length glass.
  • Rear flip-up work boards.
  • ISO outlet/CON outlets.
  • Solid interior mirror polish stainless steel, thermal glass divider or glass ends.
  • Remote glycol or CO2 refrigeration packages.


SGM

Compare

Please consult Hillphoenix Engineering Reference Manual for dimensions, plan views and technical specifications. Specifications subject to change without notice. Designed for optimal performance in store environments where temperature and humidity do not exceed 75°F and 55% R.H. Certified to UL 471, ANSI/NSF Standard 2,7,51 and CAN/CSA C22.2.
