SSD-R Single-Deck Service Refrigerated Deli and Bakery Display Case


Service Single-Deck

Hillphoenix SSD-R Single-Deck, Service, Refrigerated Display. Designed for deli and bakery applications. Curved glass profile. Available in several lengths. Optional 48-1/2″ case height lines up with the SSD-LT Gelato display.

Features and Benefits

  • Sled runner base construction.
  • Standard 50-1/2”H and 42”D .
  • 15-15/16”H toekick height.
  • 60 degree front dieboard.
  • Painted metal exterior.
  • Painted base trim to match exterior; front & sides.
  • Stainless steel exterior trim.
  • Stainless steel outside back including rear base trim.
  • 10-7/8”D x 3/8” thick glass case top.
  • 34-1/2”H stainless steel rear work ledge with 2” overhang.
  • Removable, clear plexiglas rear load doors.
  • Single-pane, regular-glare curved lift front glass.
  • Black painted metal interior and trim.
  • Black painted metal flat bottom merchandising deck.
  • LED top lighting.
  • Rear electrical raceway.
  • Energy efficient fans.
  • Solar digital thermometer.
  • Remote DX refrigeration package.

Available Options

  • Available lengths: 4’, 6’, 8’, 10’ and 12’.
  • Alternate toekick height include: 13-15/16”H with an overall height of 48-1/2”H.
  • Bullet leg base with adjustable height toekick.
  • Stainless steel base trim.
  • Cart bumper.
  • Interior and exterior stainless steel finish.
  • Exterior standard grade laminate.
  • White or other painted metal interior finish.
  • Perforated step riser.
  • Z riser.
  • Solid surface, stone, or stainless steel case top.
  • Integrated case top scale stand: Glass, SS, poly, solid surface, or stone.
  • Adjustable scale stand (interior strut – 8’-12’ models) (type: SS or poly).
  • Scale stand with dedicated circuit for ISO receptacle.
  • Curved, non-glare option on straight cases only.
  • Extended rear ledge.
  • Poly, solid surface or stone rear ledge.
  • Rear flip-up or fixed work board.
  • Front electrical raceway.
  • Con outlets or CAT5.
  • Alternative case thermometer.
  • Solid interior painted, solid interior mirror polish stainless steel, thermal glass divider or glass ends.
  • Remote glycol or CO2 refrigeration packages.


Please consult Hillphoenix Engineering Reference Manual for dimensions, plan views and technical specifications. Specifications subject to change without notice. Designed for optimal performance in store environments where temperature and humidity do not exceed 75°F and 55% R.H. Certified to UL 471, ANSI/NSF Standard 2,7,51 and CAN/CSA C22.2.
